Exakt 35 - Page 41

Spare parts and auxiliary equipment
EXAKT 35 / 50 Edition 04/09.2002
41
Item Part no. Description Quantity
Version 2: Cog belt - drive
1 11530 Reducing gear (cog belt)
2 11540 Adjustable pulley (cog belt)
3 11550 Drive pulley (cog belt)
4a 11580 Cog belt, step 1
4b 11590 Cog belt, step 2
5 11600 Cover, left side
6 11610 Cover, right side
7 11300 Plastic guide (1 unit)
8 Material specific
part no.
Rear roller
9 Material specific
part no.
Centre roller
10 Material specific
part no.
Front roller
11/12 -- Scraper system, see section 10.5
13 11690 Hand-wheel for manual roller rotation
14 11680 Rotary knob III – II – I (rear roller gap)
15 11670 Rotary knob I – II – III (front roller gap)
16 11700 Main ON/OFF switch
16a 11720 ETA circuit breaker
17 11470 Gear, front roller (single)
18 11480 Gear, centre roller (double)
19 11490 Gear, rear roller (single)
20 Bearing lever
21 Tensioning spring
22 Eccentric
23 Motor cover (middle mud-guard)
24 Main power cord with plug
25 11660 Buffer
19650 Adhesive warning labels (1 set)
