Maintenance
EXAKT 35 / 50 Edition 04/09.2002
31
!" Insert the ceramic knife (Fig. 21/d).
!" Make sure that the chamfer (Fig. 21/F)
is positioned correctly.
!" Lightly tighten the fastening screws
(Fig. 21/a) (make sure that the knife
can still be moved by hand).
!" Push the ceramic knife (Fig. 21/d)
against the spacer plate (Fig. 21/c).
!" Align the ceramic knife on the scraper
socket (Fig. 21/e).
Fig. 21: Fastening the ceramic knife
!" Carefully tighten the fastening screws
(Fig. 21/a) until the knife can no longer
be moved by hand.
Warning – Risk of damage to the ceramic knife when
making contact with the roller!
There is an increased risk of breaking a ceramic knife when
putting a used ceramic knife with a serrated or jagged edge
against the roller.
To remove the serrations on the knife-edge, place the knife
carefully against the roller with the unit running. This grinds off
any surface irregularities.
!" When putting the ceramic knife against the roller, make sure
that is has been installed straight.
!" When installing a scraper socket containing a ceramic knife
on the unit be careful not to let the socket release too
quickly and force the knife against the roller. Gently let the
socket release back to it’s operating position so that the
knife gently comes in contact with the roller.
d
a
c
e
F
