EXCELL PRECISION CO., LTD.
02018058 ZSME300000264 19
Stable Transmission (totalizing mode)
S/N WT/UNIT ( kg / lb )
- - - - - - - - - - - - - -
0001 1.0000 ( The scale is stable
0002 1.0000 ( The scale is stable
0003 1.0000 ( The scale is stable
0004 1.0000 ( The scale is stable
0005 1.0000 ( The scale is stable
- - - - - - - - - - - - - -
0005 5.0000 ( Press twice to print TOTAL
RS232 output format in HOLD MODE
Please set in .
If there is only RS-232, press to print out the HOLD value on the display.
Continuous Transmission (specific form for Brazil models)
The print out is as below:
If display shows 70.15kg, the RS-232 export is 51.07000
If display shows -70.15kg, the RS-232 export is 51.0700-
If display OL, RS-232 print nothing.
or key Transmission (specific form)
Totalization print form
F R “ W T 3 N “ <LF>
? <LF>
G G , G G G <LF>
T T , T T T <LF>
PT PT , PT PT PT <LF>
N N , N N N <LF>
pcs pcs pcs pcs pcs pcs <LF>
n n n n n n t t t t t t pcs pcs pcs pcs pcs pcs <LF>
p 1 , 1 <LF>
For example:
PT 0.3KG
T 0.7KG
G 1.2KG
N 0.2KG
PCS 20
