EXCELL PRECISION CO., LTD.
02018058 ZSME300000264
23
3-6
⇒ ID Code Setting
(Use must be in coordination with , ， ， )
Press key or key to select
function ⇒ the display shows
Press key
Press key
RS232 DATA FORMAT
Stable transmission (
), Continuous transmission (
),
Press key to transmit ( )
1. e.g. Machine ID code is 10.
The gross weight (+0.876 kg) shows as below, after stable: (no tare or pre-tare mode)
1 0 S T , G S , + 0 0 0 . 8 7 6 k g 0D 0A
ID HEAD1 , HEAD2 , DATA UNIT C LF
2. e.g. Machine ID code is 00. (Not using Machine ID function.)
The net weight (-1.568 lb) shows as below without weight stability: (under tare or pre-tare mode)
U S , N T , - 0 0 1 . 5 6 8 l b 0D 0A
HEAD1 , HEAD2, DATA UNIT C LF
Machine ID code setting:
Press and to set 01 ~ 99.
Default setting: 00
Machine ID code setting:
(1) “00”: RS-232 does not transmit Machine ID.
(2) “01~99”: RS-232 transmits Machine ID.
