Introducing the FTB-2/FTB-2 Pro and FTB-4 Pro

6 FTB-2/FTB-2 Pro and FTB-4 Pro

Main Features

Left panel

(Two-slot model)

AC adapter/charger

connector

Earth (ground) terminal

Retaining screws

for FTB modules

Security slot for Kensington lock
