Introducing the FTB-2/FTB-2 Pro and FTB-4 Pro

FTB-2/FTB-2 Pro and FTB-4 Pro 7

Main Features

Left panel

(Four-slot model)

AC power inlet

Earth (ground) terminal

Retaining screws

for FTB modules

Security slot for Kensington lock
