Operating the Optical Switch
26 Optical Switch
Installing the RTUe-9110/RTUe-9120 External Switch in a Rack
Note: The instructions presented in the procedure hereafter apply to both the
RTUe-9110 and RTUe-9120 switches regardless of which switch appears in
the illustrations.
WARNING
The equipment rack must be anchored to an unmovable
support to prevent it from falling over when one or more units
are extended in front of the rack on slides. You must also
consider the weight of any other device installed in the rack. A
crush hazard exists if the rack tilts forward, which could cause
serious injury.
Mounting of the unit in a rack or cabinet should be such that a
hazardous condition is not achieved due to uneven mechanical
loading.
CAUTION
To ensure that the RTUe-9110/RTUe-9120 external switches have
optimum support, EXFO recommends to install them on top of an
RTU-2 unit in the rack.
