Operating the Optical Switch
Optical Switch 27
Installing the RTUe-9110/RTUe-9120 External Switch in a Rack
To install your unit or external switch in a rack:
1. Ensure that no USB cable, or optical fibers are connected to the
external switch.
2. Position the switch so that its bottom panel rests on a flat surface such
as a table.
IMPORTANT
The external switches are only half a unit high.
To maximize the utilization of rack space when you install external
switches, EXFO recommends to alternate the position of the
brackets for each switch. The brackets should be placed with their
rack screw holes at the bottom for the first (primary) switch, at the
top for the second, at the bottom for the next switch, and so on
(see illustrations hereafter).
