Installing Your Unit in a Rack
4. Align the holes of the first bracket with the holes of the unit’s casing at
the position that best suits your installation needs. You can even invert
position of the mounting bracket if necessary.
Brackets in standard position - 19-inch racks
Rack screw holes at the bottom
Rack screw holes at the top
Rack screw holes
Brackets in standard position - ETSI racks
