© Boule Medical AB, March 2018. Article no. 1504496 Page 9
1. Introduction
Reagent Consumption Specications
Reagent Consumption Specications
Diluent Consumption: ≤ 25 mL per analysis cycle (with both EOS and non-EOS incubaton
enabled). ≤ 55 mL per analysis cycle with Exigo EOS incubation enabled.
Lyse Consumption: ≤ 5.2 mL per analysis cycle.
EOS Consumption: ≤ 4.0 mL per analysis cycle.
Cleaner Consumption: ≤ 35 mL during standby and power o cycles.
For additional information regarding the consumption of cleaning solutions please refer to the Boule
Cleaning Kit instruction. (Supplied with the Boule Cleaning Kit).
Regulatory Requirements
The Exigo H400 system fullls the following International standards and regulations:
SS-EN ISO 18113-3:2011
EN 61326-1 (2013) (EMC 2014/30/EU)
2012/19/EU WEEE
IEC 61010-1:2001
UL 61010-1:2004 and CAN/CSA-C22.2 No. 61010-1:2004
IEC 61010-2-081:2001 + A1:2003
IEC 61010-2-101:2002
2011/65/EU RoHS-directive
Specications
Physical
Size (Instrument version without sampler) HWD ≤ 395 × 295 × 475 mm
Weight (Instrument) ≤ 18 kg
Display Depth: True color (24-bit);
Resolution: 800 × 480 pixels
Keyboard Virtual incorporated keyboard
Communication interface ports 1 USB device/4 USB host/1 LAN port
Barcode reader input Yes (via USB)
RFID reader input Yes (via USB)
Operating Environment
Temperat u re 18–32 °C
Humidity 10%–90%
