Page 76 © Boule Medical AB, March 2018. Article no. 1504496
9. Troubleshooting and System Messages
Troubleshooting
SECTION 9. TROUBLESHOOTING AND
SYSTEM MESSAGES
Troubleshooting
General Information Displays
General information displays are informative screen displays that appear after a function has been
completed. Instruction is then displayed for the operator on next step or function to be performed.
Warning Displays
Warning displays appear after a function has been performed incorrectly or to inform the operator
that further action is needed to complete the desired task. The warning display describes the situation
and instructs the operator on next step or function to resolve the issue.
Indication Error Codes
Indications error codes are specic instrument situations that in most cases need the attention of the
operator or might need service action.
The rst indication display is the most important as it describes the issue and how to solve the
problem.
In most cases, the instrument is stopped and the operator has to conrm with OK to continue.
Once OK is pressed and instrument returns to display menus, user should repeat previous
actions again (e.g. re-analyze sample, printing results, etc.)
If indication error appears again or a three digit indication was displayed as the rst
indication message, contact local distributor or authorized service technician.
Indication Series Description
1–19 Indication series for auxiliary errors.
20–29 Indication series for Liquid System errors.
30–39 Indication series for Communication errors between the PCBs (CAN bus).
40–59 Indication series for Internet Communication errors.
60–69 Indication series for HPC errors.
70–79 Indication series for Shear Valve problems.
100–255 Indication series for internal hardware and software problems, and messages during sub-
board rmware upgrades.
