© Boule Medical AB, March 2018. Article no. 1504496 Page 49
7. Menu Structure and Advanced Setup
Menu Structure
Menu Structure
Display screens may vary pending on user
login level.
Advanced User menus highlighted in gray.
= Start Menu
= Result List
= Quick Functions
= Main Menu
= Login
Start Menu Flowchart
Start Menu
Keyboard Entry Screen
Result List
Quick Functions
Main Menu
Patient Results
Search Menu
Statistics Menu
Figure 72: Start Menu Flowchart
SECTION 7. MENU STRUCTURE AND
ADVANCED SETUP
