WEAT V2 N - V1
12GB
2. Recommended dimensions for a 120° opening (dimensions in mm)
3. Dimensions for a 90° opening to the outside post of 40 x 40 cm (dimensions in mm)
Outside
Inside
C Hole
number
DBA
30
16595150
20
16585150
A B C Opening
angle
90
50 200 90°
C. Installing the mounting brackets on the leaf :
Place the actuator on the tab of the post. Do not forget the two nylon washers on each side of the tab (one
above, and one under) Fig. 1.
Nylon
washers
Metal washer
Fig. 1
