As far as the air inlet box is concerned, there is the
possibility to connect the air inlet pipe above the sliding
base (see pict.18) or under the sliding base (see pict.19)
depending on the needs.
The fumes exhaust box is normally delivered with the rela-
tive covering top.
For the annual cleaning of the stove, we suggest to fix
the equipped flange to a suction pipe in order to make the
cleaning easier. (see pict.19).
Nb: All these operations must be carried out by a
specialized technician.
Fig. 18
Fig. 19
Sliding base
Covering top for fumes exhaust box
Air inlet box
Air inlet box
Cleaning
flange for the
fumes exhaust
box
ACCESSORY AVAILABLE ONLY ON MODEL MAXI
Put high temperature
silicone on the flange
thread and between
flange and sliding base.
