10 LIGHTING
1. Check that the hopper is loaded, that the combustion chamber is clean, that the glass door is
closed, that the power socket is connected and that the switch on the rear is in position 1.
2. Press button
1 for three seconds; for the first 10 seconds, the display D1 will show the message
“Att” with the numbers falling every second. During this stage, the stove will carry out an
auto-control and check the efficiency of every single electrical component.
When this cycle is completed, the display D1 will show the message
Acc 15 (the stove attempts
the lighting stage for 15 minutes and the number drops down by 1 every minute that passes).
NOTE:
When the hopper of the apparatus is loaded for the first time, pellets are not distributed to
the combustion chamber for 15 minutes because the worm screw for loading the pellets is
empty. The stove will automatically try another lighting phase for another 15 minutes; if the
pellets do not drop into the burning pot in this case either and the fire does not develop, the
display will show the message “NO acc”.
In this case, press button 1 for three seconds until D1 shows the message “OFF”
(note 1)
and then repeat the steps from 1 to 3.
3. If points 1 and 2 are carried out correctly, the stove will enter the lighting stage after 11 minutes
and the display D1 will show the room temperature “
20 C°” (“ t on” is displayed by D1 when
you connect a mechanical room thermostat to the stove (SEE CHAP. 10)
4. The desired heating power is adjusted by means of the buttons 4 and 5.
N.B.
In case of continued lighting failures, even if the pellets are coming out from the feeding pipe as
well, the problem could be that the electrical lighting plug is broken (note 2). In this case, contact
an authorised technician.
ATTENTION!
- NEVER USE FLAMMABLE LIQUIDS FOR LIGHTING
- WHEN FILLING, DO NOT BRING THE SACK OF PELLETS INTO CONTACT WITH THE HOT STOVE
Note 1: Check that the burning pot is completely free and clean
Note 2: In any case always check before lighting the stove that the burning pot is completely free and clean.
25
11 NORMAL OPERATION - TURNING OFF - REMOTE CONTROL
11.1 Normal operation
When the stove has been lit, the user can adjust the heating power by means of buttons 4 and
5. By pressing 4, the heating power and the pellet consumption will decrease, while by pressing
5 it will increase. The feed rate is shown on the display D2 as follows:
Heating power
display D2
1 0,4 Kg/h 0,6 Kg/h 0,6 Kg/h 0,6 Kg/h 0,6 Kg/h
2 0,6 Kg/h 1,0 Kg/h 0,85 Kg/h 0,9 Kg/h 1,2 Kg/h
3 0,8 Kg/h 1,5 Kg/h 1,1 Kg/h 1,3 Kg/h 1,8 Kg/h
4 1,0 Kg/h 2,0 Kg/h 1,35 Kg/h 1,6 Kg/h 2,4 Kg/h
5 1,2 Kg/h 2,4 Kg/h 1,6 Kg/h 2,0 Kg/h 3,0 Kg/h
Preziosa
BabyFiamma
Ecologica
Divina-Divina Plus
Bella-Bella Lux
I.C. mini
Contessa
I.C. maxi
Ecologica
Idro
CONSUMPTION
