15.3 CLEANING I.C. MINI
1. BURN POT CLEANING
The burn pot must be cleaned every day.
To do so, use the special poker(see part.B
Fig.38) to scrape off any incrustation which
may have formed in the holes. Remove the
deposited residues using a vacuum cleaner.
Remove the burn pot from its seat and
remove the ash deposits using a vacuum
cleaner.
2.
CLEANING THE HEAT EXCHANGER
Cleaning the heat exchanger allows you to
maintain a constant heat yield over time.
This type of maintenance must be carried out
at least once a day.
To do this, simply use the special scrapers
situated in the upper frontal part of the
stove. (
see Fig.39)
fig. 38
fig. 39
15.4 CONNECTION TO THE
CHIMNEY
Once a year, or whenever needed,
vacuum and duly clean the
connection to the chimney.
In case of horizontal sections,
duly remove any ash residues
(see lat. photo) before these can
obstruct the smokes flow.
Failure to the cleaning, affect the
safety of the stove.
Inspection
Inspection
Slope
Height over
Inspection
