6
TECHNICAL SPECIFICATIONS
All a.m. data are not binding, but valid just as an indication.
The right to make technical modifications for improving the product is reserved.
Height 606 mm. 550 mm.
Width 640 mm. 700 mm.
Depth 717 mm. 450 mm.
Weight 130 Kg. 110 Kg.
Fume exhaust pipe diameter 80 mm. 80 mm.
Max heating volume 190 m
3
150 m
3
Total power 2,5 - 9,4 kW/h 2,5 - 7,5 kW/h
Water power / kW/h / kW/h
Pellet consumption per hour 0,6 - 2,0 Kg/h 0,6 - 1,6 Kg/h
Absorbed electrical power 25 - 100 W 25 - 100 W
Lighting power +280 W +280 W
Power supply 230 V 50 Hz 230 V 50 Hz
Feed box capacity ~ 28 kg. ~ 12 kg.
Inlet/outlet water pipe “ / “ /
I.C. Maxi
I.C. Mini
I.C. Mini
WITH PELLET FEEDING KIT
355
141
143
97
143 355 141
1310 (circa)
1109
1029
80
97
606
423***
I.C. Maxi
*** Minimum Height
The detail “ adjustment pipe”
is pre-drilled with 3 holes Ø 8,5 : 90-100.
For other adjustments, drill according to needs.
A: FUMES OUTLET PIPE Ø80
B: AIR INTAKE PIPE Ø 50
