2 AP3935 Overview
AP3935 Overview
TheAP3935accesspointisavailableintwomodels:
• AP3935icontainseightinternalsingle‐bandantennas
• AP3935econtainseightexternalRSMAconnectorsforoptionalexternalantennas,forgreater
rangeandcoverageversatility
Figure 1‐1onpage 2showsthetopviewoftheAP3935iandFigure 1‐2onpage 3showsthetop

viewoftheAP3935e.
Figure 1‐3onpage 3showsthebottomviewoftheAP3935e.Thebottomviewshowsthelocation
oftheLANports,consoleport,externalpowersupplyconnector,andresetswitch.Thebottom
panelisthesameforbothmodels,buttherearenoexternalantennaRSMAconnectorson
the
AP3935i.
Figure 1‐4onpage 4illustratestheAP3935LEDs.
Figure 1-1 ExtremeWireless AP3935i top view
NOTE
The AP3935 comes in two models: the AP3935i has 8 internal single-band
antennas while the AP3935e has 8 external RSMA connectors for connecting
external antennas. Within this document, any reference to AP3935 applies to
both models.
