ExtremeWireless™ AP3935 Installation Guide 1
1
Introduction
ThisinstallationguideprovidesanoverviewandinstallationinstructionsfortheExtremeWireless
AccessPointsAP3935iandAP3935e.
About the AP3935i and AP3935e
TheAP3935isdesignedtoextendyourWirelessLANaroundindoorlocations.TheAP3935
supportsthe802.11acand802.11nwirelessstandards,withfullbackwardcompa tibilitywith
legacy802.11a,and802.11b/gdevices.
TheAP3935interoperatesfullywithWirelessLANs,includingsupportforVoWLAN,branch
officemode,guestservices,RTLS,availability,andmobility
features.TheoperatingTemperature:
0‐50C.
TheAP3935iandAP3935ehavethefollowingfeaturesincommon:
•BothsupporttwoMIMO4x4(uptofour802.11acspatialstreams).
•Theyprovidetwosinglebandradiosfordual‐band,concurrentoperation,optimizedfor
indoorantennacoverage:
–5GHz(Radio1)inanyofthefollowing
modes:IEEE802.11ac,a/b/gand/orn
–2.4GHz(Radio2)inanyofthefollowingmodes:IEEE802.11ac,a/b/gand/orn
•Theyareenclosedinarectangular,compactcase.
•Bothmodelscanbemountedonwallsanddrop/suspendedceilings.
•Theyprovide80MHzBandwidthat2.4/5GHzoperation(ChannelBonding).
•Powerisprovidedthrough
twoEthernetports(LANport).Thisisthepreferredmethodof
poweringtheAPonceilingandwallinstallations.TheAP3935canalsobepoweredbyan
externalDCpowersupplybypluggingthesupply’sinputjackintotheDC‐Inport.
For information about... Refer to page...
About the AP3935i and AP3935e 1
AP3935 Overview 2
Architectural Features 5

Extreme Networks ExtremeWireless AP3935i Specifications

General

Brand	Extreme Networks
Model	ExtremeWireless AP3935i
Category	Wireless Access Point
Language	English
