4 AP3935 Overview
AP3935 LED Indicators
BothmodelsoftheAP3935have theLEDindicators,showninFigure 1‐4below.TheLEDsprovide
statusinformation,describedinTable 1‐1,onthecurrentstateoftheAP3935.Formore
information,seetheExtremeWirelessUserGuide.
Figure 1-4 AP3935 LEDs
1 Status 4 Radio 1 (5 GHz)
2 LAN 1 (Ethernet 1) 5 Radio 2 (2.4 GHz)
3 LAN 2 (Ethernet 2)
Table 1-1 AP3935 LED Indications
LED Status Description
1 (AP status) On Green Indicates the AP3935 is working
normally.
Flashing Green Indicates:
• running a self test
• loading software program
On Amber Indicates a CPU/system failure.
