IN1604 DTP and IN1604 HD Scalers • SIS Configuration and Control 35
Command ASCII Command
(host to scaler)
Response
(scaler to host)
Additional Description
Active pixels
Specify a value
EX&APIX} ApixX!*X&] Set the active pixels to X& on the current
input.
Increment value
E+APIX} ApixX!*X&]
Increase the active pixels on the current input.
Decrement value
E-APIX} ApixX!*X&]
Decrease the active pixels on the current
input.
View
EAPIX} X&]
View the active pixels on the current input.
Active lines
Specify a value
EX*ALIN} AlinX!*X*] Set the active lines to X* on the current input.
Increment value
E+ALIN} AlinX!*X*]
Increase the active lines on the current input.
Decrement value
E-ALIN} AlinX!*X*]
Decrease the active lines on the current input.
View
EALIN} X*]
View the active lines on the current input.
3:2, 2:2, 24:1 Film mode detect
Auto
EX!*1FILM} FilmX!*X(]
Set film mode detection to automatic (default).
Off
EX!*0FILM} FilmX!*X(]
Disable film mode detection.
View setting
EX!FILM} X(]
View the current film mode setting.
HDCP authorized setting (valid for HDMI inputs only, to allow or block HDCP input signals)
Enable HDCP
authorization
EEX!*1HDCP} HdcpE X!*1]
Enable HDCP authorization.
Disable HDCP
authorization
EEX!*0HDCP} HdcpE X!*0]
Disable HDCP authorization.
Query HDCP
authorization status
EEX!HDCP} X4$]
HdcpEX!*X4$]
View HDCP authorization setting.
Verbose mode 2 and 3
HDCP status (valid for HDMI inputs and the DTP output only)
Query input
EIX!HDCP} X3!]
HdcpIX!*X3!]
View the HDCP status on input X!.
Verbose mode 2 and 3
Query output
EO1HDCP} X3!]
HdcpO1*X3!]
View the HDCP status on the output.
Verbose mode 2 and 3
NOTES:
X! = Input selection 1 = configurable VGA
2 = HDMI/DVI 1
3 = HDMI/DVI 2
4 = HDMI/DVI 3
X& = Active pixels ±512 of the default value
X* = Active lines ±256 of the default value
X( = Enable or disable 0 = off or disabled
1 = on or enabled
X3! = HDCP status 0 = no sink or source device detected
1 = sink or source detected with HDCP
2 = sink or source detected but no HDCP is present
X4$ = HDMI input HDCP authorization status 0 = block HDCP encryption
1 = allow HDCP encryption (default)
