Extron electronics IN1604 DTP - On-Screen Menu Configuration Commands; Device Commands

IN1604 DTP and IN1604 HD Scalers • SIS Configuration and Control 45
Command ASCII Command
(host to scaler)
Response
(scaler to host)
Additional Description
On-Screen Menu Configuration Commands
Front control panel emulation
Toggle menu
EMMENU} Menu*M]
Toggle the OSD menu.
Enter menu
EAMENU} Menu*A]
Enter OSD menu.
Exit menu
EXMENU} Menu*X]
Exit OSD menu.
Enter
EEMENU} Menu*E]
Emulate the Enter button.
Up arrow
EUMENU} Menu*U]
Emulate the Up button.
Down arrow
EDMENU} Menu*D]
Emulate the Down button.
Left arrow
ELMENU} Menu*L]
Emulate the Left button.
Right arrow
ERMENU} Menu*R]
Emulate the Right button.
View OSD menu status
EMENU} X(]
MenuX(]
Show the status of the OSD menu.
Verbose mode 2 and 3
Device Commands
Reset
Reset all device settings to
factory default
EZXXX} Zpx]
Reset all device settings the factory
defaults.
Verbose mode
Set verbose mode
EX2$CV} VrbX2$]
Enable or disable verbose mode
and tagged responses, where
additional information is provided in
response to a query.
View verbose mode
ECV} X2$]
View the verbose mode.
Unit name
Set unit name
EX2%CN} Ipn
•
X2%]
Set the device name to X2%.
NOTE: Characters must be from the alphabet (A-Z), digits (0-9), or the minus or hyphen sign (-). Lowercase
and uppercase letters are interchangeable. The first character must be an alpha character. The last
character cannot be a minus sign or hyphen.
View unit name
ECN} X2%]
View the device name.
Reset unit name
E
•
CN} Ipn
•
IN1604
•
DTP]
or
Ipn
•
IN1604
•
HD]
Reset the device name to the
factory default. The device name
depends on the device model.
NOTES:
X( = Enable or disable 0 = off or disabled
1 = on or enabled
X2$ = Verbose mode 0 = clear or none
1 = verbose mode (default for RS-232 and USB connections)
2 = tagged responses for queries
3 = verbose mode and tagged queries
X2% = Device name text label up to 24 characters
