IN1604 DTP and IN1604 HD Scalers • SIS Configuration and Control 46
Command ASCII Command
(host to scaler)
Response
(scaler to host)
Additional Description
Information request
General Information
I
Vid
X!
•
TypX@
•
StdX1)
•
AmtX(
•
...
BlkX2(
•
HrtX1@
•
VrtX1@]
Query firmware version
Q
x.xx
]
View firmware version.
Query full firmware version
*Q
x.xx.xxxx
]
View full firmware version.
Query boot loader version,
factory firmware version,
and current firmware version
0Q x.xx-x.xx.xxxx-
x.xx.xxxx]
View boot loader version,
factory firmware, and current
user firmware.
Query part number
N
<part number>
]
View the part number.
View internal temperature
E20STAT} X1!]
20Stat
•
X1!]
View the temperature in
degrees Celsius.
Verbose mode 2 and 3
View device description
2i
SCALING
•...
PPRESENTATION
•...
SWITCHER]
View the unit description.
View DTP protocol
EO1HDBT} X4%]
HdbtO1*X4%]
View the current twisted pair
output format for the output.
Verbose mode 2 and 3
NOTES:
X! = Input selection 1 = configurable VGA
2 = HDMI/DVI 1
3 = HDMI/DVI 2
4 = HDMI/DVI 3
X@ = Input video format 1 = RGB
2 = YUV
3 = S-video
4 = Composite
5 = HDMI
X( = Enable or disable 0 = off or disabled
1 = on or enabled
X1) = Input standard 0 = no signal detected on the current input
1 = NTSC 3.85
2 = PAL
3 = NTSC 4.43
4 = SECAM
- = N/A
X1! = Internal temperature In degrees Celsius
X1@ = Horizontal and vertical frequency
X2( = Video mute on all outputs 0 = all outputs are unmuted
1 = at least one output is muted
2 = at least one output is muted and sync is disabled
X4% = DTP output format 0 = DTP format (default)
1 = HDBaseT format
