IN1604 DTP and IN1604 HD Scalers • SIS Configuration and Control 36
Command ASCII Command
(host to scaler)
Response
(scaler to host)
Additional Description
Picture Adjustment Commands
Contrast
Specify a value
EX1$CONT} ContX!*X1$]
Set the contrast for the current input.
Increment value
E+CONT} ContX!*X1$]
Increase the contrast.
Decrement value
E-CONT} ContX!*X1$]
Decrease the contrast.
View
ECONT} X1$]
View the contrast setting.
Brightness
Specify a value
EX1$BRIT} BritX!*X1$]
Set the brightness on the current input.
Increment value
E+BRIT} BritX!*X1$]
Increase the brightness.
Decrement value
E-BRIT} BritX!*X1$]
Decrease the brightness.
View
EBRIT} X1$]
View the brightness setting.
Detail filter
Specify a value
EX1$HDET} HdetX!*X1$]
Set the detail filter for the current input.
Increment value
E+HDET} HdetX!*X1$]
Increase the detail.
Decrement value
E-HDET} HdetX!*X1$]
Decrease the detail.
View
EHDET} X1$]
View the detail filter setting.
Color (NTSC, PAL, and SECAM inputs only)
Specify a value
EX1$COLR} ColrX!*X1$]
Set the color level on the current input.
Increment value
E+COLR} ColrX!*X1$]
Increase the color level.
Decrement value
E-COLR} ColrX!*X1$]
Decrease the color level.
View
ECOLR} X1$]
View the color level setting.
Tint (NTSC inputs only)
Specify a value
EX1$TINT} TintX!*X1$]
Set the tint on the current input.
Increment value
E+TINT} TintX!*X1$]
Increase the tint.
Decrement value
E-TINT} TintX!*X1$]
Decrease the tint.
View
ETINT} X1$]
View the tint setting.
Auto Memories
Enable
EX!*1AMEM} AmemX!*1] Enable Auto Memory on input X!.
Disable
EX!*0AMEM} AmemX!*0] Disable Auto Memory on input X!.
View
EX!AMEM} X(]
View the Auto Memories status.
NOTES:
X! = Input selection 1 = configurable VGA
2 = HDMI/DVI 1
3 = HDMI/DVI 2
4 = HDMI/DVI 3
X( = Enable or disable 0 = off or disabled
1 = on or enabled
X1$ = Picture adjustment 0-127 (64 = default)
