Extron electronics IN1604 DTP - Preset Commands

IN1604 DTP and IN1604 HD Scalers • SIS Configuration and Control 38
Command ASCII Command
(host to scaler)
Response
(scaler to host)
Additional Description
Preset Commands
User presets
Recall preset
1*X2). 1RprX2)] Recall user preset X2).
Save preset
1*X2), 1SprX2)]
Save the current picture controls.
Delete preset
EX1*X2) PRST} PrstX1*X2)] Clear user preset X2).
User preset name
Write name
E1*X2),X1#PNAM} Pnam1*X2),X1#] Set user preset X2) name to X1#.
View name
E1*X2)PNAM} X1#] View the name of user preset X2).
NOTE: To clear a user preset name, enter a single space character for X1#. This resets the user preset name
to the default value, “[User Preset XX].” This is valid only for existing presets.
Input presets
Recall preset
2*X2!. 2RprX2!] Recall input preset X2!.
Save preset
2*X2!, 2SprX2!]
See the table below for settings
saved on input presets.
Delete preset
EX2*X2! PRST} PrstX2*X2!] Clear input preset X2!.
Input preset name
Write name
E2*X2!,X1# PNAM} Pnam2*X2!,X1#] Set input preset X2! name to X1#.
View name
E2*X2!PNAM} X1#] View the name of user preset X2!.
NOTE: To clear an input preset name, enter a single space character for X1#. This resets the input preset name
to the default value, “[Input Preset XXX].” This is valid only for existing presets.
Saved Settings for User Presets Saved Settings for Input Presets
Color Detail Input Type Contrast V Start Image H/V Position
Tint Preset Name Preset Name Brightness H Active Image H/V Size
Contrast Image H/V Position Audio Gain/Attenuation Detail V Active
Brightness Image H/V Size Color Total Pixels Phase
Tint H Start Film Mode
NOTES:
X1# = Text label Up to 16 characters
X2) = User presets 1-16
X2! = Input presets 1-16
