IN1604 DTP and IN1604 HD Scalers • SIS Configuration and Control 37
Command ASCII Command
(host to scaler)
Response
(scaler to host)
Additional Description
Horizontal shift (image)
Specify a value
EX1%HCTR} HctrX1%] Set the horizontal position to X1%.
Increment value
E+HCTR} HctrX1%]
Increase the horizontal position.
Decrement value
E-HCTR} HctrX1%]
Decrease the horizontal position.
View
EHCTR} X1%]
View the horizontal position setting.
Vertical shift (image)
Specify a value
EX1^VCTR} Vctr X1^] Set the vertical position to X1^.
Increment value
E+VCTR} VctrX1^]
Increase the vertical position.
Decrement value
E-VCTR} VctrX1^]
Decrease the vertical position.
View
EVCTR} X1^]
View the vertical position setting.
Horizontal size (image)
Specify a value
EX1&HSIZ} HsizX1&] Set the horizontal size to X1&.
Increment value
E+HSIZ} HsizX1&]
Increase the horizontal size.
Decrement value
E-HSIZ} HsizX1&]
Decrease the horizontal size.
View
EHSIZ} X1&]
View the horizontal size setting.
Vertical size (image)
Specify a value
EX1*VSIZ} Vsiz X1*] Set the vertical size to X1*.
Increment value
E+VSIZ} VsizX1*]
Increase the vertical size.
Decrement value
E-VSIZ} VsizX1*]
Decrease the vertical size.
View
EVSIZ} X1*]
View the vertical size setting.
Compound image position and size
Specify a value
EX1%*X1^*...
X1&*X1*XIMG}
XimgX1%*X1^*X1&*X1*]
Set the horizontal and vertical
positions and sizes.
View
EXIMG} X1%*X1^*X1&*X1*]
View all position and size settings.
NOTES:
X! = Input selection 1 = configurable VGA
2 = HDMI/DVI 1
3 = HDMI/DVI 2
4 = HDMI/DVI 3
X1% = Horizontal position ±2048
X1^ = Vertical position ±1200
X1& = Horizontal size 0-4096
X1* = Vertical size 0-2400
