NBP Series Reset Mode Summary
Mode
Use This
Mode to...
Activation Result
Reset All IP Settings
Reset IP
settings and
port maps
to factory
defaults
without
affecting
user-loaded
files
To reset all IP settings:
1. Press and hold the Reset button for about 6seconds until
the Reset LED blinks twice (once at 3 seconds, again at
6seconds).
2. Release and press the Reset button momentarily (for
<1second) within 1second*.
* Nothing happens if the momentary press does not occur
within 1second.
NOTE: This reset also turns DHCP off.
Reset All IP Settings mode:
• Sets the IP address back to factory default
(192.168.254.253)
• Sets the subnet back to factory default
(255.255.255.0)
• Sets the default gateway address to the
factory default (0.0.0.0)
• Sets domain and host names to factory
default
• Turns DHCP off
Reset to Factory Defaults
Start over with
configuration
and uploading
To reset the unit to all factory default settings:
1. Hold down the Reset button for about 9seconds until the
Reset LED blinks three times (once at 3 seconds, again at
6seconds, again at 9 seconds).
2. Release and press the Reset button momentarily (for
<1second) within 1second*.
* Nothing happens if the momentary press does not occur
within 1second.
Reset to Factory Defaults mode performs
a complete reset to factory defaults
(except the firmware).
• Does everything Reset All IP Settings mode
does
• Removes (clears) all user-loaded files and
configurations from the NBP
• Clears driver-port associations
(Ethernet) and port configurations
NOTE: After performing a Reset All IP Settings or Reset to Factory Defaults reset, use
Toolbelt to set the IP address again for use on your network.
