Network Button Panels • Software-Based Configuration and Control 33
• Verify that the NBP buttons and knobs (where applicable) are configured correctly.
• For digital input and output connections, verify whether the application requires the
+5VDC pull-up resistor within the control processor or receiver for TTL circuits and use
the software to check whether it is selected within the configuration.
• Verify that input current at any digital input or output port on the control processor or
receiver does not exceed 250mA.
• Verify that input current at the volume control port on an IPCPPro250 does not exceed
10VDC and that the amplifier is cabled correctly, as well.
If you are still experiencing problems, call the Extron S3 Sales & Technical Support
Hotline or the Extron S3 Control Systems Support Hotline (1.800.633.9877).
