Extron electronics ShareLink Pro 500 - Command and Response Tables for SIS Commands

ShareLink Pro 500 • SIS Configuration and Control 30
Command and Response Tables for SIS Commands
Command ASCII Command
(Host to Device)
Response
(Device to Host)
Additional Description
Video input selection
Select HDMI window input
E1PIPS} Pips1]
De-select HDMI window input
E0PIPS} Pips0]
View HDMI window input
EPIPS} X!]
Select HDMI pass-through input
1!
In1]
De-select HDMI pass-through input
0!
In0]
View HDMI pass-through input
!
X!]
InX!]
(Verbose mode 2/3)
Query HDMI input signal presence
E0LS} X@]
In00
•
X@]
(Verbose mode 2/3)
Query HDMI input signal detected
rate
E1LS} X#]
In01
•
X#]
(Verbose mode 2/3)
View detected format
1*\
X$]
Vtyp1*X$]
View video format on HDMI input
(Verbose mode 2/3)
Input EDID (HDMI)
Import EDID (.bin) to input (store)
slot
EIX%,<filename>
EDID}
EdidIX%]
Import EDID from <filename> to
input slot X%
Export EDID (.bin) to PC
EEX%,<filename>
EDID}
EdidEX%]
Export EDID from EDID table slot
X% to <filename>
View EDID native resolution
ENX%EDID} X^]
EdidNX%*X^]
View native resolution and refresh
rate of EDID from EDID table slot
X%. (Ex: 1920x1080@60.00Hz)
(Verbose mode 2/3)
View/read EDID of input in Hex
format
ER1EDID} X&]
EdidR1*X&]
(Verbose mode 2/3)
KEY:
X! = Input window status
0 = HDMI window not displayed 1 = HDMI window displayed
X@ = Input signal
0 = No input signal detected 1 = Input signal detected
X# =
HDMI input signal detected rate (Ex: 1920x1080@60.00Hz); no signal = 0x0@0Hz
X$ = Video format
0 = No signal, 1 = DVI, 2 = HDMI
X% = EDID table slot
X^ = Native resolution & refresh rate
Ex: 1920x1080@60.00Hz
X& = EDID data in Hex
