ShareLink Pro 500 • Reference Information 47
Reference
Information
This section covers the following:
• Mounting
• Firmware Download
• Firewall Traversal
• Troubleshooting
Mounting
The ShareLink Pro 500 can be placed on a tabletop, or mounted in a rack or underneath a
desk.
NOTE: Do not block or restrict air ventilation holes on the top and sides of the
ShareLink Pro 500.
Tabletop Mounting
Attach the provided rubber feet to the bottom four corners of the enclosure.
Furniture Mounting
Go to www.extron.com for a list of available furniture mounting kits. To install this device to
furniture, follow the mounting kit instructions.
Rack Mounting
UL Guidelines for Rack Mounting
The following Underwriters Laboratories (UL) guidelines are relevant to the safe installation of
this product in a rack:
• Elevated operating ambient temperature — If the unit is installed in a closed or
multi-unit rack assembly, the operating ambient temperature of the rack environment
may be greater than room ambient temperature. Therefore, install the equipment in
an environment compatible with the maximum ambient temperature (TMA = +122 °F,
+40°C) specified by Extron.
• Reduced air flow — Install the equipment in the rack so that safe operation and
adequate air flow is provided to the unit.
• Mechanical loading — Mount the equipment in the rack so that a hazardous
condition is not achieved due to uneven mechanical loading.
• Circuit overloading — Connect the equipment to the supply circuit and consider the
effect that circuit overloading might have on overcurrent protection and supply wiring.
Consider the equipment nameplate ratings when addressing this concern.
