ShareLink Pro 500 • SIS Configuration and Control 31
Command ASCII Command
(Host to Device)
Response
(Device to Host)
Additional Description
Output Rate
Set output rate
E1*X*RATE} Rate1*X*]
Set output rate
View output rate
E1RATE} X*]
Rate1*X*]
View output rate
(Verbose mode 2/3)
KEY:
X* = Output rate (see the table below; default = 45).
Resolution 23.98 Hz 24 Hz 25 Hz 29.97 Hz 30 Hz 50 Hz 59.94 Hz 60 Hz
640x480
10
800x600
11
1024x768
12
1280x768
13
1280x800
14
1280x1024
15
1360x768
16
1366x768
17
1440x900
18
1400x1050
19
1600x900
20
1680x1050
21
1600x1200
22
1920x1200
23
480p
24 25
576p
26
720p
29 30 31 32 33 34
1080i
35 36 37
1080p
38 39 40 41 42 43 44 45*
