ShareLink Pro 500 • SIS Configuration and Control 32
Command ASCII Command
(Host to Device)
Response
(Device to Host)
Additional Description
Screen saver
Set output sync
mode
EM1*X(SSAV} SsavM1*X(]
View output sync
mode
EM1SSAV} X(]
SsavM1*X(]
(Verbose mode 2/3)
Set time out duration
ET1*X1)SSAV} SsavT1*X1)]
Set the time out duration to
X1)
seconds
View time out
duration
ET1SSAV} X1)]
SsavT1*X1)]
View current time out duration X1)
(Verbose mode 2/3)
View screen saver
status
ES1SSAV} X1!]
SsavS1*X1!]
View the current screen saver status
status X1!
(Verbose mode 2/3)
Color bit depth
Set video bit depth
EV1*X1@BITD} BitdV1*X1@]
Query video bit depth
EV1BITD} X1@]
BitdV1*X1@]
View color bit depth
(Verbose mode 2/3)
Video output format
Set format
E1*X1#VTPO} Vtpo1*X1#]
Set output video format
View setting
E1VTPO} X1#]
Vtpo1*X1#]
View output video format
(Verbose mode 2/3)
KEY:
X( = Output sync mode
0 = Sync always active (default)
1 = No signal present timer, disable output
2 = Inactivity timer, disable output
X1) = Time out duration
0-999999 (1 second increments)
1000000 = Never times out
Default = 30 seconds
X1! = Screen saver status
0 = Active input detected; timer not running
1 = No active input; timer is running; output sync still active
2 = No active input; timer has expired; output sync disabled
X1@ = Color bit depth
0 = Auto mode (default) 1 = Force 8-bit
X1# = Output video format
0 = Auto (default) 1 = DVI RGB 4:4:4 Full
2 = HDMI RGB 4:4:4 Full 3 = HDMI RGB 4:4:4 Limited
4 = HDMI YUV 4:4:4 Limited 5 = HDMI YUV 4:2:2 Limited
6 = HDMI YUV 4:2:0 Limited
