ShareLink Pro 500 • SIS Configuration and Control 39
Command ASCII Command
(Host to Device)
Response
(Device to Host)
Additional Description
Standby screen/status bar configuration
Set status bar mode
EM
X4*OSDL} OsdlM
X4*]
View status bar mode
EMOSDL} X4*]
OsdlM
X4*]
(Verbose mode 2/3)
Set enable/disable status
bar pop-up
EP
X7(OSDL} OsdlP
X7(]
View status bar pop-up
EPOSDL} X7(]
OsdlP
X7(]
(Verbose mode 2/3)
Set status bar pop-up timer
ET
X79!OSDL} OsdlT
X79!]
View status bar pop-up
timer
ETOSDL} X79!]
OsdlTX79!]
(Verbose mode 2/3)
Set label
ELX4(*X5)OSDL} OsdlLX4(*X5)]
View label
ELX4(OSDL} X5)]
OsdlLX4(*X5)]
(Verbose mode 2/3)
Show label and value
EVX4(*1OSDL} OsdlVX4(*X5!]
Hide label and value
EVX4(*0OSDL} OsdlVX4(*X5!]
Query label visibility
EVX4(OSDL} X5!]
OsdlVX4(*X5!]
(Verbose mode 2/3)
Set background color
EKX7&OSDL} OsdlKX7&]
View background color
EKOSDL} X7&]
OsdlKX7&]
(Verbose mode 2/3)
Set font color
ECX7&OSDL} OsdlCX7&]
View font color
ECOSDL} X7&]
OsdlCX7&]
(Verbose mode 2/3)
Set still image transition
effect
EEX5#SSHW} SshwEX5#]
View still image transition
effect
EESSHW} X5#]
SshwEX5#]
(Verbose mode 2/3)
KEY:
X4* = Status bar mode
0 = Never shown 1 = Always shown (default)
2 = Not shown only when one content is shared
3 = Not shown when one or more content is shared
X4( = Label
1 = Hostname 2 = IP address A 3 = IP address B,
4 = Login code 5 = Custom message
6 = Dynamic notifications/messages 7 = Clock
X5) = Label value (max 128 characters)
X5! = Label visibility setting
0 = Hide 1 = Show (default)
X5# = Still image transition effect
0 = Cut (default) 1 = Fade
X7& = Color described as RGB Hex triplets (RRGGBB)
X7( = Status bar pop-up
0 = Disabled 1 = Enabled (default)
X79! = Status bar pop-up timer
1 s - 300 s in 1 s increments (default = 20 s)
