2A PREPARING THE LEAVES
Preparetheleavesasdescribedbelow.
1. Secureto the leaf, the leaffitting profile cutto the same
length,andsecureitwithadequatescrewsontheupper
part(fig.17).
2. Placetwocarriagesoneachleafmakinguseofthesupplied
platesandscrews;thenmounttheleafandcarriageuniton
theslidingprofile,asshowninfig.18a b c.
3. Securethecarriages onthe leaf,usingthe dimensionsin
figure9forthedoubleleaf,andfig.7-8forthesingleleaf.
Tightenthecarriagesecuringscrews.
4. Cutthelowerguideprofiletothesamelengthastheleaf
andsecurewithadequatescrewsonthelowerpart.
5. Ifspecified,insertthebrushintheseatoftheslidingprofile
Fig.19ref.a.
UseanAllenkeyM5.
UseanAllenkeyM5.
Tolockthe2Allenscrewsofthesideandcentralmechanical
stops,useanAllenkeyM5(fig.15andfig.16).
fig. 18
fig. 17
fig. 19
fig. 15
fig. 16
fig. 14
Important : place the side and central mechanical stops
  correctly, abutting with the profile, before
  blockingthem(fig.14
c).
