B. INSTALLATION OF ASSEMBLED AUTOMATED SYSTEM
SECURING THE ON-WALL SUPPORT PROFILE
RefertochapterAofthekitautomatedsysteminstallation.
fig. 53
Thereare2typesofaluminiumprofilesforthecrossbeam:
-Support profile
Thesupportprofileisusedtosecuretheautomatedsystemtoaloadbearingstructureinmetalormasonry,freeofanysignificant
deformation.
Positionthecrossbeamonthefloor,withdrawthe‘parachute’cablesfromthehousing,andremovethehousing.Ifnecessary,
removefromtheprofilealsothosecomponents(e.g.motor,carriages,transmissionpulley)whichcouldhamperyouwhilesecuring
tothewall,looseningthenutsfromtheplates.
Tothenpositiontheremovedparts,refertofigures7-8-9.
Free-standing profile
Itisthealuminiumprofilewhich,assembledtothesupportprofile,grantsthefree-standingfeaturetothecrossbeam.
Itisusedwhenthecrossbeamcannotbecompletelysecuredtoabearingstructureorwhenthesupportsurfaceisnoteven
