5.2.2 Meaning of the LED‘s
LED "AGITATOR”
during cooling mode Agitator is switched on
LED "COMPRESSOR“
on Compressor contactor is switched on
off Compressor contactor is switched off
flashing Pause time compressor (pendulum protection)
LED "T1” or „T2"
T1 on Set target temperature for "T1" is active
T2 on Set target temperature for "T2" is active
LED “ERROR”
flashing The control is in error mode and must be
acknowledged with the "OFF" button.
LED “END OF CLEANING / TANK EMPTY”
permanent Cleaning successfully finished -
tank is ready for further filling.
LEDs in cooling mode
LEDs in cleaning mode
T1
T2
T1
T2
T1
T2
!
!
Page 13
Mode
Cooling
Agitation
Washing
Pneumatic outlet valve ON/OFF
5. Operation
