Working level
for normal daily operation
Switch to level
“Extended cooling parameters”
See section 8.1.
P parameters
Code: D345
EMERGENCY COOLING, behavio r sensor failureu on Range Default
P4 Manual start of compressor x min.for 0 .. 60 min. 0
in case of sensor failure
Function see section .69
Compressor protection when filling from below Range Default
P6 Compressor switch-on delay / pre-agitating 0 .. 180 sec. 0
Function see section .59
0: Function deactivated
1 to 180: Time delay compressor in sec.
Limit setting for set temperatures and hysteresis Range Default
Setting of limitations for target temperatures and
hysteresis in C parameter level.
P10 Lower limit for target temperature T1 - o C1 0 .. 50,0 °C 2,0f r
P11 Upper limit for target temperature T1 - o C1 0 .. 50,0 °C 8,0f r
P12 Lower limit for target temperature T2 - o C2 0 .. 50,0 °C 2,0f r
P13 Upper limit for target temperature T2 - o C2 0 .. 50,0 °C 8,0f r
P15 Lower limit for hysteresis T1 - o C10 0,1 .. 30,0 K 0,1f r
P16 Upper limit for hysteresis T1 - o C10 0,1 .. 30,0 K 2,0f r
P17 Lower limit for hysteresis T2 - o C11 0,1 .. 30,0 K 0,1f r
P18 Upper limit for hysteresis T2 - o C11 0,1 .. 30,0 K 2,0f r
Agitator settings Range Default
P22 Function intermediate stirring 0 .. 2 1
see section 5.6.3
0: deactivated
1: short / long
2: toggling by button
P23 Automatic start to continuous stirring 0 .. 1 0
when cooling mode ends
see section .10.19
0: deactivated
1: activated
P2 4 Monitoring agitator directly [F54] 1 0 .. 1
see section 7.5.4
0: deactivated
1: activated
General cooling parameters code: C212
Extended cooling parameters code: D345
General cleaning parameters code: B454
Extended cleaning parameters code: C567
Service parameter s code: EA03
General tank monitor parameters code: 4711
Extended tank monitor parameters code: F94A
Alarm configuration code: FFFF
Configuration code: A384
I/O test parameters code: 10E5
8.3 Level “Extended cooling parameters” (P parameters)
8. Setting of parameters
Page 46
