Working level
for normal daily operation
Adjustment to safety elements
r10 Safety switch butterfly valve (F40) see section .2 9 (Default 0)
Parameter is hidden, if parameter [A40] = 2 or 3
0: no safety switch
1: prevents the start of cooling / cleaning,
when switch is not in proper position
2: as + abort of cleaning when switch in the wrong position1
r11 Cleaning pump monitoring via pressure switch (Fault F41) (Default )10
For dry running protection of the cleaning pump (open in case of fault)
0: deactivated
1 .. 20: Stop cleaning after x seconds without pressure
r12 Cleaning pump fault thermo contact switch (Fault F42) (Default 0)
To protect the cleaning pump (open in case of fault)
0: no thermo contact switch
1: thermo contact switch active
r18 (Default 0)Activation of compressor in the final rinse
0: deactivated
1: activated. (In purging step n84, compressor is activated when the tank
temperature is between 40°C and 4 °C)
Detergent options
r20 Dosing position (see section and .15)6.2 9 (Default 2)
0: dosing in feed container (displacement cleaning)
in cleaning diagram1: position D1
2: position D2 in cleaning diagram
r21 Detergent sequence in case of 3-cycles (Default )1
(if second main cleaning stage is deactivated)
0: only alkaline
1..10: x times alkaline, before one time acid
r23 Setting of drain valve in pre-rinse 2 during filling via water reservoir
0: drain valve closed, 1: drain valve opened 1(Default )
Drain valve settings
r24 drain valve 1 Switching mode (Default )1
0: normally closed 1: opencurrentless
r25 drain valve 2 Switching mode (Default 0)
0: normally closed 1: opencurrentless
Switch to level
“Extended cleaning parameters”
See section 8.1.
r parameters
Code: C567
General cooling parameters code: C212
Extended cooling parameters code: D345
General cleaning parameters code: B454
Extended cleaning parameters code: C567
Service parameter s code: EA03
General tank monitor parameters code: 4711
Extended tank monitor parameters code: F94A
Alarm configuration code: FFFF
Configuration code: A384
I/O test parameters code: 10E5
8.5 Level “Extended cleaning parameters” (r parameters)
8. Setting of parameters
Page 54
