Settings to start cleaning (see section .3.1)9
r27 Cleaning enable via digital input (Default 0)
0: deactivated
1: activated
Short wash configuration Range Default
r28 Activation of short program via button 1 .. 8 0
0: deactivated
1: 1x Pre-wash 1 (Rinse 1)
2: 1x Pre-wash 2 (Rinse 2)
3: 1x After-wash (Rinse 8)
4: 1x After-wash (Rinse 9)
5: 2x Pre-wash 1 (Rinse 1)
6: 2x Pre-wash 2 (Rinse 2)
7: 2x After-wash (Rinse 8)
8: 2x After-wash (Rinse 9)
Settings for level detection (see also section .14)9
r30 Sensitivity level input 1 (Default 0)
-10: less sensitive
+10: more sensitive
r31 Sensitivity level input 2 (Default 0)
-10: less sensitive
+10: more sensitive
r32 Timeout water intake by level (Fault F44) (Default 5)
Maximum time to cleaning abort: 1 .. 60 min.
r33 Level monitoring at the end of the cleaning stages (Fault F45) (Def 0).
0: deactivated
1: Level 1 monitoring only after the last cleaning stage.
activate alarm message F45 and alarm relays.
2: Level 1 monitoring after each cleaning stage.
activate alarm message F45 and alarm relays.
3: Level 2 monitoring only after the last cleaning stage.
activate alarm message F45 and alarm relays.
4: Level 2 monitoring after each cleaning stage.
activate alarm message F45 and alarm relays.
r34 Inlet pipe water detection. Max. time above the level (Default 0)
0: deactivated
1...300 sec.
Setting of heater
r35 Heater activation (Default 1)
0: no heater
1: only in main cleaning stage 1
2: in both main cleaning stages 1+2
3: in both main cleaning stages 1+2 and disinfection
r36 Start delay heater (Default 0)
Range: 0 .. 120 sec.
r37 Max. running time heater (Timeout programme step “H”) (Default 60)
Range: 10 .. 999 min. (Fault F48)
r38 Heater protection via pressure switch (Default )5
0: deactivated
1.. 8 sec.: Switch off the heater after x seconds without pressure
r39 Over temperature protection heater (Fault F49) (Default 0)
To protect the heater (open in the fault)event of a
0: No protective contact
8. Setting of parameters
