Number of passes of seperate cleaning stages Range Default
r40 Number of passes clean. stage 0: Rinse out 0 .. 5 0
r41 Number of passes clean. stage 1: Pre-rinse 1 0 .. 5 1
r42 Number of passes clean. stage 2: Pre-rinse 2 0 .. 5 1
r43 Number of passes clean. stage 3: Main rinse 1 1 1
(not changeable)
r44 Number of passes clean. stage 4: Interm . rinse 1 ed 0 .. 5 1
r45 Number of passes clean. stage 5: Main rinse 2 0 .. 1 0
r46 Number of passes clean. stage 6: Interm . rinse 2 ed 0 .. 5 1
r47 Number of passes clean. stage 7: isinfection D 0 .. 1 0
r48 Number of passes clean. stage 8: fter-rinse A 0 .. 5 0
r4 Number of passes clean. stage : inse9 9 R out 0 .. 5 0
Selection of water valve (cold / hot water) Range Default
r50 Valve selection clean. stage 0: Rinse out 1 .. 4 1
r51 Valve selection clean. stage 1: Pre-rinse 1 1 .. 4 1
r52 Valve selection clean. stage 2: Pre-rinse 2 1 .. 4 3
r53 Valve selection clean. stage 3: Main rinse 1 1 .. 4 2
r54 Valve selection clean. stage 4: Intermitt. rinse 1 1 .. 4 1
r55 Valve selection clean. stage 5: Main rinse 2 1 .. 4 1
r56 Valve selection clean. stage 6: Interm . rinse 2 ed 1 .. 4 1
r57 Valve selection clean. stage 7: isinfection D 1 .. 4 1
r58 Valve selection clean. stage 8: After-rinse 1 .. 4 1
r5 Valve selection clean. stage : inse 9 9 R out 1 .. 4 1
1: Cold water
2: Warm water
3: Cold and arm water (mixed)w
4: Hot water
5: H and cold waterot water
6: H and warm waterot water
7: H and warm water and cold waterot water
Selection of drain valve Range Default
r60 Drain valve select. clean. stage 0: Rinse out 1 .. 2 1
r61 Drain valve select. clean. stage 1: Pre-rinse 1 1 .. 2 1
r62 Drain valve select. clean. stage 2: Pre-rinse 2 1 .. 2 1
r63 Drain valve select. clean. stage 3: Main rinse 1 1 .. 2 1
r64 Drain valve select. clean. stage 4: Interm . rinse 1 ed 1 .. 2 1
r65 Drain valve select. clean. stage 5: Main rinse 2 1 .. 2 1
r66 Drain valve select. clean. stage 6: Interm . rinse 2 ed 1 .. 2 1
r67 Drain valve select. clean. stage 7: isinfection D 1 .. 2 1
r68 Drain valve select. clean. stage 8: After-rinse 1 .. 2 1
r6 Drain valve select. clean. stage : inse 9 9 R out 1 .. 2 1
1: Drain valve 1
2: Drain valve 2
8.5 Level “Extended cleaning parameters” (r parameters)
8. Setting of parameters
From option 4 onwards, the
function A 16 (hot water valve)
must additionally be assigned
to one of the relays in the A
parameters.
In case of selection , the 2
function A 1 ( valve) must 5 drain
additionally be assigned to one
of the relays in the A
parameters.
Page 56
