8. Setting of parameters
Settings cleaning breaks
r70 Activation of break in cleaning programme (Default 0)
0: deactivated
1: activated, finish of break only with button or digital input
2: activated, finish of break after time [r72] or button or digital input
3: activated, finish of break at a certain time [r73] or button or digital input
r71 Position break: (Default 1)
After which cleaning stage is the break integrated
Setting range: after cleaning stage 0….8
r72 Break time 0...999 min. (Default 120)
r73 Finish of the break at time 00:00 … 23:59 00:00
Settings of cleaning pump (see section 9.13)
r80 Cleaning pump venting (Default 0)
0: deactivated
On-/off-impulses with a fixed quantity for all cleaning stages1:
2: as 1, however, premature termination if pressure via pressure switch
3: as 1, however, unlimited impulses when rinsing (cleaning stages 0+9)
4: as 2, however, unlimited impulses when rinsing (cleaning stages 0+9)
r81 Number of on / off pulses cleaning pumpim 3)(Default
Range: 0 .. 10
r82 ON pulse length cleaning pumpim (Default )3
Range: 0 .. 10 sec.
r83 OFF pulse length cleaning pumpim (Default )3
Range: 0 .. 10 sec.
Service settings for commissioning
r92 Start cleaning at the beginning of cleaning stages 0..8 (Default 0)
Range: 0 .. 8
r93 Number of cleaning cycles with step function (Default 0)
Range: 0 .. 3
r97 Display during cleaning (Default 0)
0: Display of programme step
1: Display of temperature
2: Display changes between step and temperature
r98 Display max. cleaning temperature reached (Default 0)
0: deactivated
1: alternating with the time
8.5 Level “Extended cleaning parameters” (r parameters)
Selection 1, 2, 3:
If the digital input is to be used
to terminate the pause, the
function 15 must additionally
be assigned to one of the
digital inputs A21-A28 in the A-
parameters.
