Robot operation
Using the ROBOT STOP button, the operation of a connected robot is either
stopped or enabled.
With the start / stop of the robot, the cooling mode of the milk tank is simultaneously
started / stopped.
Hold down the ROBOT STOP button for approx. 3 seconds: robot operation is
either enabled or stopped (Toggle function)
Cleaning mode
Press the “WASH” button: )(from OFF mode
Cleaning proceeds automatically in line with your settings.
Depending on the setting in [r97], the display indicates the current cleaning
stage or the temperature.
Exception: During the heating stages the current water temperature is displayed.
Setting parameter [ ] = 1 dr98 isplay max. cleaning temperature reached allows to
after wash cycle is completed.
To stop cleaning manually
Press OFF button for 3 seconds: The cleaning programme switches to the stop
phase. “ABL” and “F43” flash alternately in the display, indicating “outlet valve
open”.
All currently active relays are de-energised
(apart from “Cleaning active” and “Robot stop”)
The outlet valve opens for a pre-set time and then closes again.
The “WASHING” LED blinks - code F43 flashes in the display.yellow
The control unit switches to OFF mode only when the OFF button is pressed
again.
Cleaning does not start
There are various possible causes – depending on parameter settings:
The robot has not been stopped -> Stop.
The butterfly valve is still closed -> Open.
The safety switch is in the wrong position.
No cleaning release from the robot
Displays during main wash
during intake of alkaline detergent: "ALC“
during intake of acidic detergent: "ACI“
during disinfecting: “dESI“
during heating the temperature alternates with "HEAt“
only if the robot is configured
5.2.4 Operation of working level
5. Operation
