An additional time can be defined in parameter [n15], in which the drain valve
opens (agitator and cleaning pump continue to run)
Agitator and pump switch off.
Outlet valve opens for the pre-set time [n16]. See also [n15].
Cleaning stage 2: PRE-RINSE 2
Parameter [r42] = 0 ‘Cleaning stage 2’ disabled
Parameter [r42] = 1..5 ‘Cleaning stage 2’ execute x-times
In case of cleaning method 'green' – it is set in programme step [n 0] how often 2
the feed container is filled with water up to level 2 and water is pumped back up
to level 1. As long as the rinsing pump is running, the drain valve is open.
Water is taken in.
The parameter [n21] is used to stipulate whether water will be taken by level or
time.
If time-controlled, the water intake time is defined in parameter [n22].
The cleaning parameter [r52] is used to stipulate whether cold, hot or mixed
water is to be taken in.
If, in the event of intake by level, the level is not reached after a pre-set time
[r32], the cleaning cycle is interrupted. See section .5.3 - F447
Agitator and pump start to run.
Another option is to select an 'additional water intake time' using [n23].
The water circulates for the pre-set time [n24].
An additional time can be defined in parameter [n25], in which the drain valve
opens (agitator and cleaning pump continue to run)
Agitator and pump switch off.
Drain valve opens for the pre-set time [n26]. See also [n25].
Cleaning stage 3: MAIN WASH 1
Parameter [r43] = 1 not changeable
In case of cleaning method 'green' – it is set in programme step [n30] how often
the feed container is filled with water up to level 2 and water is pumped backup
to level 1. The drain valve remains closed up to cleaning step [n35/n36].
( ) Settings for version 6.1.4 dosing in pre-hopper
Parameter [r20 = 0] and parameter [n30 = min. 2] since the detergent is added
when water is taken from the pre-hopper for the second time.
Water is taken in.
The parameter [n31] is used to stipulate whether water will be taken by level or
time.
If time-controlled, the water intake time is defined in parameter [n32].
If, in the event of intake by level, the level is not reached after a pre-set time
[r32], the cleaning cycle is interrupted. See section .5.3 - F447
The cleaning parameter [r53] is used to stipulate whether cold, hot or mixed
water is to be taken in.
Agitator and pump start to run. Water circulates in the tank.
Another option is to select an 'additional water intake time' using [n33].
6.3 Explanation and programming of the cleaning process
* (D1 or D2 in cleaning programme diagram)
6. Cleaning
In case of green
n 41 have to be
parameterized on „0“
In case of green
n2 n21 and 2 have to be
parameterized on „0“
In case of green
n23 n24 and have to be
parameterized on „0“
In case of green
n3 n31 and 2 have to be
parameterized on „0“
In case of green
n33 have to be
parameterized on „0“
