10. CONTROLLING THE APPLIANCE
10.1 Lighting the fire
If the main burner or pilot light is extinguished for any reason, do not
attempt to relight the pilot within 5 minutes. Contact a qualified
installer when the appliance goes off regularly.
We advise to leave the pilot flame on. Leaving the pilot flame on reduces
condensation and increases the life span of the appliance.
The control valve is behind the door or ash pan cover. Open the door.
With control button A you can light the pilot. With the control button B
you can adjust the height of the flames (see fig. 26 below).
Knob A
The z is the OFF position preventing any gas from passing through the
control valve to either the pilot burner or to the main burner. By pressing
the knob in it is possible to turn it anticlockwise. The first function is to
turn on the gas to the pilot- this occurs just before reaching the
position (if the fire has not been lit for some time it may be necessary to
hold the knob in this position for some seconds to clear the air from the
pipe and allow gas to reach the pilot burner).
fig. 28: Gas control block front
