40 < < < <
Once gas is available at the pilot, continued rotation anti-clockwise will
cause the piezo igniter to spark. This is accompanied by a click at the
valve and should result in the pilot burner igniting. Once the pilot is lit,
the control knob should be held pressed in for 10 seconds. In this time the
pilot flame will have heated the flame supervision thermocouple
sufficiently to operate a hold-on magnet within the valve. Now turn the
control knob A to the
position. This allows gas to enter control knob B.
Knob B
The z is the OFF position preventing gas entering the main burner if the
pilot is lit. The knob should be turned slowly anticlockwise. This allows
gas to enter the burner and be ignited by the pilot flame. Once ignition
has aken place, the fire may be set to any level between min. and max.
by adjusting the control knob B.
10.2 To light
1) Push in and turn the control knob (A) from z anticlockwise to the
setting
(small flame). You will hear an ignition click. Check that
the pilot is lit (if not repeat).
2) Continue to hold in the control knob for a further ten seconds to
ensure that the pilot flame is stable.
3) Release the knob. The pilot should remain alight.
4) Turn the control knob A to the
position.
5) Turn knob B slowly anticlockwise, the fire should then ignite.
6) Adjust flames to the required level.
10.3 To extinguish
1) For the main burner turn the control knob B clockwise to position z;
