Facility Explorer FX16 - Specifications and Technical Data

FX16 Master Controller Technical Bulletin 117
Specifications and Technical Data
Ordering Codes
Table 28: FX16D Master Controller
Ordering Codes Description
LP-FX16D00-000C
FX16 Master Controller, 6 AI, 8 DI, 4 AO, 9 DO (relays), no communications card
LP-FX16D01-000C
FX16 Master Controller, 6 AI, 8 DI, 4 AO, 9 DO (relays), N2 Open communications
card
LP-FX16D02-000C
FX16 Master Controller, 6 AI, 8 DI, 4 AO, 9 DO (relays),
LON communications card
LP-FX16D03-000C
FX16 Master Controller, 6 AI, 8 DI, 4 AO, 9 DO (relays), RS-232C communications
card
LP-FX16D10-000C
FX16 Master Controller, 6 AI, 8 DI, 4 AO, 9 DO (4 relays + 5 triacs), no
communications card
LP-FX16D11-000C
FX16 Master Controller, 6 AI, 8 DI, 4 AO, 9 DO (4 relays + 5 triacs), N2 Open
communications card
LP-FX16D12-000C
FX16 Master Controller, 6 AI, 8 DI, 4 AO, 9 DO (4 relays + 5 triacs), LON
communications card
LP-FX16D13-000C
FX16 Master Controller, 6 AI, 8 DI, 4 AO, 9 DO (4 relays + 5 triacs), RS-232C
communications card
Table 29: FX16X Rev. A Master Controller Extended Temperature Range
Ordering Codes Description
LP-FX16X00-000C
FX16 Master Controller, 6 AI, 8 DI, 4 AO, 9 DO (relays), no communications card
LP-FX16X01-000C
FX16 Master Controller, 6 AI, 8 DI, 4 AO, 9 DO (relays), N2 Open communications
card
LP-FX16X02-000C
FX16 Master Controller, 6 AI, 8 DI, 4 AO, 9 DO (relays),
LON communications card
LP-FX16X03-000C
FX16 Master Controller, 6 AI, 8 DI, 4 AO, 9 DO (relays), RS-232C communications
card
LP-FX16X10-000C
FX16 Master Controller, 6 AI, 8 DI, 4 AO, 9 DO (4 relays + 5 triacs), no
communications card
LP-FX16X11-000C
FX16 Master Controller, 6 AI, 8 DI, 4 AO, 9 DO (4 relays + 5 triacs), N2 Open
communications card
LP-FX16X12-000C
FX16 Master Controller, 6 AI, 8 DI, 4 AO, 9 DO (4 relays + 5 triacs), LON
communications card
LP-FX16X13-000C
FX16 Master Controller, 6 AI, 8 DI, 4 AO, 9 DO (4 relays + 5 triacs), RS-232C
communications card
