Facility Explorer FX16 - GSM Connection

FX16 Master Controller Technical Bulletin
124
GSM Connection
Table 44: GSM Modem
GSM Modem GSM 900 GSM 1800/1900
Voltage Range
5 to 32 VDC
Power Supply at 25°C
Min. Typ. Max. Min. Typ. Max.
Input Supply Voltage
5 13.2 32 5 13.2 32
at 5 V 1.8 A 1.1 A
at 13.2 V 0.7 A 0.4 A
Input peak supply
current (in
communication)
at 32 V 0.4 A 0.2 A
at 5 V 330 mA 220
mA
at 13.2 V 130 mA 95 mA
Input average supply
current (in
communication)
at 32 V 65 mA 50 mA
at 5 V 31.4
mA
31.4
mA
at 13.2 V 13.2
mA
13.2
mA
Input average supply
current (in idle
mode)
at 32 V 5.6 mA 5.6 mA
Ambient Operating
Conditions
-20°C (-4°F) to 55°C (131°F)
Ambient Storage
Conditions
-25°C (-13°F) to 70°C (158°F)
Housing Material
Aluminum profiled
Volume
12.2 cm
3
(0.7 in.
3
)
Weight
<130 g (0.3 lb)
Dimensions
98 mm (3.9 in.) x 54 mm (2.1 in.) x 25 mm (1 in.)
(excluding connectors)
Overall Dimensions
110 mm (4.3 in.) x 54 mm (2.1 in.) x 25 mm (1 in.)
