FX16 Master Controller Technical Bulletin
94
Note: The FX16 Master Controller manages two main processes
working on the same RS-232C modem port: the Web server and the
SMS server. The two processes share the RS-232C plug-in card
applying a time-sharing philosophy. If an event goes into the active
state and it requires an SMS transmission, the SMS server and E-mail
have a higher priority over the Web server.
Events Plug-In
FX Builder includes an Events Plug-In, which allows you to configure
the events needed to treat and the type of treatment to use.
The Events Menu Item opens the Event Plug-In (Figure 83).
The LP-FX16 (not Rev. A) Master Controller handles 20 events,
whereas the latest LP-FX16X Rev. A Master Controller handles up to
250 events.
Figure 83: Event Maker Screen
You can define events on binary (two state) or enumerated (multistate)
variables in the Network Profile or in the Application Profile. Another
group of events are defined as the System Events Group and comprise
predefined event conditions related to the proper execution of the
application.
The message destinations are the available contacts and groups defined
in the Address Book. The message destinations enable the user to select
the required destination for the selected event. You must uniquely
define each final destination in case the user wants to send notification
to more than one contact. The final destination can also be a group
definition within the Address Book. Groups contain all the contacts to
receive a notification at the same time.
