Page 6/7 Installation

4.2 Pin Assignment

The wiring must be carried out only with the power disconnected. Special local

rules and regulations of relevant Professional Associations and Authorities must

be observed (e.g. VDE in Germany).

Observe the maximum values of the operating parameters that are stated in the

Technical Specifications.

Figure 2: Evaluation unit UM-X, pin assignment

4.2.1 Sensor Connection

The sensor is connected to the terminals 1 (-) and 2 (+).

Display connection

Sensor

Acknowledge

button

Power Supply

Membrane

keyboard

Ack.
