Operation Page 11/12
6.4 Main Menu
The main menu is called up from the "Column display" or "Relay status" display with the but-
ton next to the symbol [M].
You may select the following menu items:
• Unit - Setting the unit
• Height - Setting the container height
• Offset - Setting the distance from the container bottom to the 4-mA-point of the
level sensor
• Span - Selection menu for sensor adjustments, e.g. pressure sensors
• Relays - Selection menu for configuring the relays
• Test - Selection menu for manual control of the relays
• Display - Selection menu for adjusting the display backlight
• Reset - Selection menu for resetting of all values to the factory setting
• Info - Display of device information
If you are in a menu for more than 3 minutes without making any further inputs, the display
automatically returns to the last view - column presentation or relay status. Changes to pa-
rameters, which have not been confirmed are not saved.
6.4.1 Navigation
There are four functions available for scrolling through the different menu items, for calling up
the selected menu item and for saving changed parameters.
Figure 6: Main menu with navigation functions
RETURN
DOWN
BACK
